The liteServer Rough.mini is particularly suitable for use in demanding areas. It is the perfect complement to our cameras in low-light areas.
Camera images are scene-dependent and depend on the lighting conditions! The liteServer Rough.mini has a built-in, energy-efficient, long-life 16W LED. The switching options (control via a process control system/camera system and on-site control with our magnet) enable maximum flexibility and safety in use for unobtrusive monitoring even in the dark.

• Application Range for Temperatures from -50°C to +50°C
• Efficient Long-Life LED-Technology
• Controlable via Magnet (mag.ON Technology)
• Switchable via I/Os
• Robust Stainless Steel Housing
• Integrated EMC-Filter (acc. EN55015 and FCC part 15)
• Extensive Accessories

More light, expanded switching options, proven dynamics in the interior

The liteServer Rough.mini is the big brother of the liteServer Rough.micro. The high-performance LED is housed in a slightly larger housing. More space is used for more features. The light output is higher (16W LED), and more switching options could be integrated.

Advanced switching options - Innovation - mag.ON^®

The liteServer Rough.mini offers a choice of different switching options:

• Via an external trigger, via a process control system or automatically via a camera with motion detection (the liteServer switches on as soon as the camera detects movement).
• Alternatively, via our latest innovation mag.ON^® , an on-site magnetic switch. This can be switched via an integrated magnetic sensor, with a choice of switch-on times of 1, 3 and 10 minutes.
• A combination of both switching options

Robust lighting

During the development of the liteServer Rough.mini, great importance was attached to safety, mechanical precision, long-lasting LED technology and high-quality stainless steel. In addition, a modular structure was at the forefront of the development.
With regard to the technical characteristics, we have gone to the limits of what is feasible: In areas such as media resistance and ambient temperature, we are setting standards with the liteServer series.

Outstanding images despite low-light conditions

A high image quality is of crucial importance in order to clearly capture a process and to be able to clearly identify the persons or objects involved. Our liteServer series was developed to optimize the performance of our CCTV cameras in difficult lighting conditions (up to absolute darkness) and to provide an intelligent security solution.

Demanding environment - no problem

The liteServer Rough.mini works reliably in the temperature range from -50°C to +50°C.

Thanks to its high-quality materials, the liteServer series is resistant to a large number of media! The specially designed GYLON flat seals (PTFE) not only make the luminaire waterproof (IP68) and resistant against water jets (IP66), but also resistant to a large number of chemicals. The extremely robust, scratch- and impact-resistant borosilicate glass fits seamlessly into the list of high-quality materials.

How is the illumination?

High light output thanks to the built-in high-power 16W COB LED cold white (5000K) with a beam angle of <100°, perfect for environments where high concentration and precision are required. The LED unit is replaceable.
